TR-ES02 High Lumen Brightness All In One Solar LED Street Light with Type C charger and IP65 Water Resistance

Name: TR-ES02 High Lumen Brightness All In One Solar LED Street Light with Type C charger and IP65 Water Resistance
Brand: Foshan Kaicheng Lighting Co., Ltd.
SKU: TR-CS
Price: 7 USD
Availability: InStock

Quality TR-ES02 High Lumen Brightness All In One Solar LED Street Light with Type C charger and IP65 Water Resistance factory

Product Specification

Place of Origin: Guangdong China

Brand Name: KCD

Certification: ce, RoHS, EMC

Model Number: TR-CS

Minimum Order Quantity: 2 pieces

Price: US $7/ Piece

Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,PayPal

Supply Ability: 100000 Piece/Pieces per Month

Product Details

Highlight:

high lumen solar LED street light

IP65 waterproof solar street light

solar street light with Type C charger

Solar Panel: 6V20W Solar Panel(mono Crystalline Silicon)

Battery Capacity: 20AH

Lumen: 110 Lm/w

Led Chips Brand: SMD2835

Led Life Time: 50000hours

Viewing Angle: Light Angle Adjustable

Work Time: 10-12 Hours Per Day, 5-7 Days Back Up

Working Temperature: -20℃~+50℃

Mounting Height: 6-8m

Color: Black

Product Description

TR-ES02 High Lumen Brightness All In One Solar LED Street Light with Type C charger and IP65 Water Resistance

TR-CS High Lumen Brightness All In One Solar LED Street Light with Type C charger and IP65 Water Resistance

Product Introduction

The TR-ES02 is a high-performance all-in-one solar LED street light engineered for modern outdoor illumination needs, combining advanced solar technology, intelligent control, and rugged durability in one compact, installation-ready unit. Designed to serve a wide range of applications — from urban streets and industrial compounds to parking lots, parks, and remote off-grid locations — this luminaire delivers reliable, energy-free lighting without the need for trenching, wiring, or ongoing electricity costs.

At the heart of the TR-ES02 is a high-efficiency SMD2835 LED array delivering 110 lumens per watt, for a total output of 10,000 lumens — equivalent to a traditional 300W fixture. The optical PC lens achieves 92% light transmittance, ensuring uniform illumination with no dark spots or glare. Users can select from three color temperatures (3000K warm white, 4000K natural white, and 6500K cool white) to match the desired ambiance and functional requirements of the installation site.

Power autonomy is ensured by a 6V 20W monocrystalline silicon solar panel paired with a 20AH LiFePO4 battery, providing 10-12 hours of continuous operation per full charge with a 5-7 day backup reserve for overcast weather conditions. The LiFePO4 battery chemistry offers superior thermal stability, long cycle life, and reliable performance even in sub-zero temperatures, making this fixture suitable for year-round deployment in diverse climates.

The luminaire features a unique dual-axis adjustable mounting bracket supporting 120° vertical tilt and 350° horizontal rotation, allowing precise beam targeting without tools. The housing is constructed from UV-stabilized ABS+PC engineering plastic capable of withstanding temperatures from -20°C to +50°C, and the IP65-rated sealed enclosure provides complete protection against dust ingress and water jets, ensuring long-term reliability in harsh outdoor environments. Anti-theft screws, a physical waterproof switch, and an optional remote control for wireless brightness and mode adjustment complete its practical design.

Certified to CE, RoHS, and EMC standards, the TR-ES02 is available with a low minimum order quantity of just two pieces and supports OEM/ODM customization with various packaging options. With a monthly production capacity exceeding 100,000 pieces, this fixture is ideal for municipal tenders, commercial projects, and wholesale distribution — delivering an optimal balance of quality, performance, and cost-effectiveness for any solar lighting initiative.
